LiDAR SZT-R250
- ● Absolute accuracy down to 5 cm
- ● 2.1 kg only, working range up to 250 m
- ● Multi-platform (UAV/SUV/ATV) applications
Additional information
| Weight | 2.1 kg |
|---|---|
| Dimensions | 297 × 85 × 111 mm |
Specification
| LiDAR System | Laser Channels | — |
| Laser Range | max. 250 m | |
| Field of View | 0°~ 360° | |
| Angular Resolution | 0.001° | |
| Max. Means Rate | up to 100,000 meas./sec | |
| Accuracy | H/V: 5 cm @50 m; H/V: 10 cm@100 m (UAV) H/V: 3 cm (Automotive) | |
| Camera Effective Pixels | 24.3 MP RGB | |
| Recommended scanning height AGL | 10-100 m | |
| Net Weight | 2.1 kg (w/o camera) | |
| Dimensions | 297 x 85 x 111 mm | |
| Input Voltage | 11-32V DC | |
| Power Consumption | 27 W | |
| Data Storage | — | |
| Part I: Laser Scanner | Type | RIEGL miniVUX-1UAV |
| Wavelength | 905 nm | |
| Eye Safety Class | laser class 1 | |
| Laser Product Classification | — | |
| Laser Pulse Repetition Rate | 100 kHz | |
| Range Accuracy | — | |
| Accuracy/ Precision | 15 mm / 10 mm | |
| Rotation Rate | — | |
| Scan Speed | 10-100 scans/sec | |
| Multi-echo effect | up to 5 echoes per shot | |
| Data Storage | SDHC/SDXC 32 GB ( 128 GB max.) | |
| Environment Protection | IP64 | |
| Temperature | operating: -10° to 40°C; storage: -20° to 50°C | |
| Part II: POS System | Type | SPAN IMU-IGM-S1 |
| Gyroscopes Bias in-run Stability | 0.05°per hour | |
| Gyroscopes Measurement Range | 400 deg/sec | |
| Accelerometers Measurement Range | ±10 g | |
| Post Processing Roll/Pitch Accuracy | 0.006° | |
| Post Processing Heading Accuracy | 0.019° | |
| Post Processing Position H/V Accuracy | 0.01/0.02 m | |
| Post Processing Velocity H/V Accuracy | 0.02/0.01 (m/s) | |
| Data Sampling Rate | POS: 125 Hz; Location: 5 Hz | |
| Internal Memory | 8 GB |
Note: all information above is subject to change without any prior notice.
Brochure Download
Download Brochure
