South X5

$3,000

  • CAD: $3,864.90

Android, 220 channels,L1,GPS+GLONASS+BDS+GALILEO, Handheld DGPS receiver, SBAS tracking, WM system,WiFi connnection,4G

● HD large 5inch touch screen which fulfill the Android users needs
● New design appearance and very comfortable to hold
● Quad-Core 1.3GHz processor
● Micro-USB port and OTG function
● Being equipped with laser centering component improving the accuracy
● More sensors are installed, electronic compass, gravity sensor, Built-in thermometer, atmospheric pressure altimeter,etc.

SKU: 5072015 Category:

Features

X5 adopts professional GPS module, 220 channels, GPS, GLONASS and BDS tracking, ensure faster satellite tracking and more reliable positioning result. As one of the best sold product of South Group, X5 can be widely used in the variety GIS field. For example, forestry investigation, agriculture management, land resource investigation, underground pipe and cable detection, geodetic control survey, etc.

X5

The Polar X5 handheld is from the South Polar X series family of integrated, rugged, and high-accuracy GNSS handhelds. As a streamlined solution that enables faster and more productive data collection, the Polar X5 is ideal for organizations, such as utility companies, municipalities, and environmental agencies, requiring mobile data collection and asset management solutions.

15381050486824781

Perfect for asset management and data maintenance projects, everything is integrated into a convenient, rugged package: high sensitivity GNSS, Windows Embedded Handheld operating system or Android operating system, Office applications, camera, and cellular connectivity.

Brand

South Instrument

Geomatics Gear – info@geomaticsgear.com – Call 1-888-410-1210. Equipment and software solutions for conventional, GNSS, UAV/drone, LiDAR, GIS, mapping and hydrographic equipment

SOUTH-LOGO-4

Additional information

Weight 1 kg
Dimensions 231 × 92 × 57 mm

Specification

System Operating system Android 5.1/6.0
CPU Octa-Core 1.5GHz
Memory 3GB RAM, 32GB ROM
Storage up to 128G extensible
GNSS performance Channels 220
GPS L1
GLONASS L1
BDS B1
GALILEO
SBAS
QZSS
Data output NEMA-0183
I/O protocol RTCM2.3 (1, 3, 9), RTCM31
Update rate 1Hz
Reacquisition < 1s
Warm start
Cold start < 30s
Accuracy Single positioning 2.5m
SBAS positioning Horizontal: 0.50m
Vertical: 0.85m
DGNSS Horizontal: 0.25m + 1ppm
Vertical: 0.50m + 1ppm
RTK(baseline<30km)
Multimedia Camera 8.0 megapixel AF, flashlight
Display 5.0 inch capacitive screen, 1280 × 720
Sensor Electronic compass, gravity sensor, built-in thermometer, atmospheric pressure altimeter, light sensor and distance sensor (optional)
Other function Laser centering, external antenna port, integrated speakers and microphone
Extended function(optional)
Communication network LTE 4G modem
Bluetooth BT4.0 downward compatible to BT2.1 + EDR
WIFI IEEE 802.11 b/g/n
USB Micro USB, support charging and OTG function
Electrical Battery 3.7V, 7200mAh Li-Ion, 2 batteries (standard)
Battery life Single battery > 10 hrs
Battery charging 2 stands charger, 4 hrs fast charging
Environment Waterproof/Dustproof IP67
Shockproof 1.5m
Humidity
Operating temperature
Storage temperature -40℃ ~ 80℃
Physical Dimension 231mm(L) × 92mm(W) × 57mm(H)
Weight 0.56kg (battery included)

Note: all information above is subject to change without any prior notice.
