Kolida K3
Extra small size, 181 channels, support all constellations, BEIDOU signal receiving capability enhanced.
Make It Small to Minimize Fatigue
The diameter of the K3 is only 13cm, height only 8.53cm, and the weight is only 820g. It is as small as an apple that you can even put it into your pocket.
181 channels,Enhanced BEIDOU.
K3 is equipped with a high performance 181 channels GNSS board which is capable to support multiple satellite constellations: GPS, GLONASS, BEIDOU and GALILEO, including the latest Beidou-3 system.
High Technology Integration
GNSS antenna, Bluetooth, wifi module are integrated into one board, which helps to save the internal space of K3, making the signal better and performance more stable.
Fully-sealed Rugged & Durable
K3 is able to withstand 2 meters pole drop onto the cement ground naturally and fully protected against blowing dust. 4 hours quick charge is enough to enable K3 a 14 hours of using time.
New Case
Easy to Carry
The dimension of the new carrying case of K3 is only 37cm x 30.5cm x 16.9 cm, with instrument inside it weights only 4.9kg. The case is made of wear-resistant materials.
Additional information
| Weight | .820 kg |
|---|---|
| Dimensions | 130 × 85.3 mm |
Specification
| Satellite Tracking Ability | ||
| Channels181 | ConstellationGPS, GLONASS, BEIDOU, GALILEO, SBAS | MSS L-BandPreserved |
| Positioning Output Rate1Hz-50Hz | Initialization Time＜10s | |
| Positioning Precision | ||
| UHF RTKHorizontal ±8mm + 1 ppmVertical ±15mm + 1ppm | Network RTKHorizontal ±8mm + 0.5ppmVertical ±15mm+0.5ppm | RTXHorizontal ±2cmVertical ±5cm |
| Static and Fast StaticHorizontal ±2.5mm + 0.5ppmVertical ±5mm + 0.5ppm | RTK Initialization Time 2-8s | |
| User Interaction | ||
| Operation SystemLinux | Web UIYes | WifiYes |
| Voice GuideYes | Data Storage 8GB internal; up to 32GB external. | |
| Working Capability | ||
| RadioBuilt-in receiving | Tilt Survey N/A | Electronic BubbleYes |
| Endurance＞14 hours (static mode), 10to 14 hours (rover mode) | OTG Function (Field Download) yes | Other Function Mobile Reference Station (wifi) |
